Specifications
NOMINAL IMPEDANCE | 8 |
SENSITIVITY | 87dB (2.83V/ 1m) |
FREQUENCY RESPONSE | 52Hz - 20kHz (±6dB) 2pi/open-backed |
CROSSOVER FREQUENCIES | 4kHz |
DRIVE UNITS | LF: 130mm(5.25in.) HF: 19mm (0.75in.) |
RECOMMENDED AMPLIFIER POWER | 10 - 80W |
PRODUCT EXTERNAL DIMENSIONS | Diameter : 193.4mm (7.61in.) Depth : 83.5mm (3.29in.) |
CUT-OUT DIMENSIONS | Diameter : 158mm (6.22in.) |
MOUNTING DEPTH FROM SURFACE | Product only: 78mm (3.07in.) |
OPTIONAL ROUGH IN FRAME | RIF130R |
UNIT MEASUREMENT | Piece |
Applications
The Ci Series Ci130CR is best suited for high quality music and speech reinforcement applications requiring hi-fi performance such as:
- Multi Room systems
- Home Theatre systems
- Lounges, Bars, Boutiques
- Boardrooms & Offices
- Airports, Convention Centres, Hotels
- Live Theatre/Concert Hall fill-in
- Houses of Worship
- Sports Arenas
