Specifications

NOMINAL IMPEDANCE  8
SENSITIVITY   87dB (2.83V/ 1m)
FREQUENCY RESPONSE  52Hz - 20kHz (±6dB) 2pi/open-backed
 CROSSOVER FREQUENCIES 4kHz
 DRIVE UNITS LF: 130mm(5.25in.)
HF: 19mm (0.75in.)
RECOMMENDED AMPLIFIER POWER  10 - 80W
 PRODUCT EXTERNAL DIMENSIONS Diameter : 193.4mm (7.61in.)
Depth : 83.5mm (3.29in.)
 CUT-OUT DIMENSIONS Diameter : 158mm (6.22in.)
 MOUNTING DEPTH FROM SURFACE Product only: 78mm (3.07in.)
OPTIONAL ROUGH IN FRAME  RIF130R
 UNIT MEASUREMENT Piece



Applications

The Ci Series Ci130CR is best suited for high quality music and speech reinforcement applications requiring hi-fi performance such as:

  • Multi Room systems
  • Home Theatre systems
  • Lounges, Bars, Boutiques
  • Boardrooms & Offices
  • Airports, Convention Centres, Hotels
  • Live Theatre/Concert Hall fill-in
  • Houses of Worship
  • Sports Arenas
