Technology

"Sit anywhere" Uni-Q sound

The Uni-Q driver array places the tweeter in the centre of the midrange and bass cone, bringing the acoustic ideal of a single point source closer than ever. The result, enhanced by KEF's 'tangerine' waveguide over the tweeter, is a more accurate three-dimensional sound that's dispersed evenly throughout the room.

Tweaking the tweeter

With the addition of the damped tweeter loading tube providing a gentle termination of sound produced from the back of the tweeter, lower treble performance is improved dramatically and a new low-distortion inductor on the crossover provides cleaner bass.

A word about drums and bass

The Q Series reproduces the nuances of bass instruments with ease. With a larger roll surround and new suspension KEF drivers produce cleaner bass at high volumes.

A new cone structure improves midrange clarity and an enhanced Auxiliary Bass Radiator (ABR) with a new surround and rear suspension enhances bass quality.

New system design

Putting the Uni-Q driver in its own sealed cabinet reduces the load on the cone and increases clarity and detail while delivering cleaner bass. Midrange clarity is enhanced by driver improvements that mean the DC blocking capacitor to be eliminated from the crossover, allowing a more natural roll-off between drivers.

Weight

5.6kg (12.3lbs)

Dimension (H X W X D)

303 x 180 x 278 mm
307 x 180 x 278 mm (with Rubber Feet)

Design

2-way bass reflex

Unit Measurement

Pair

Sensitivity

86dB (2.83V/1m)

Frequency Range Free Field

47Hz (-6dB)

Frequency Response

51Hz-28kHz (±3dB)

Maximum Output

108dB

Amplifier Requirements

10-100W

Nominal Impedance

8 Ohms (min.3.7 Ohms)

Drive Units

130mm (5.25in.) aluminium Uni-Q
25mm (1in.)vented aluminium dome HF

Crossover Frequencies

2.5kHz

Finishes

Satin Black / Satin White

Downloads

Q Series User ManualQ Series Information SheetQ Series Brochure
