THE STRADIVARI'S VIOLIN

Inspired by the shape of Lilium, Il Cremonese is a tribute to the most famous creation of Antonio Stradivari. Its five non-parallel walls structure and the sides applied on the enclosure, requires a careful processing techniques, as for a musical instrument: from the wood bending and shaping, to the treatments of the precious Avional surfaces.

THE ORETICAL PERFECTION

This is what we have in mind in designing the “acoustic environment” of each single transducer. Each volume is insulated with different materials from open cell thermoplastic foam to fibrous materials, similar to the felt used in pianos. The most appropriate material or materials are selected for each specific application.

FEATURES

This atypical Sonus faber form represents an evolution towards technological
and visual innovation, simultaneously maintaining the historic milestones
that marked the history of violin making, as well as the history of the Sonus faber brand itself.

RHOMBOIDAL DIAMOND DESIGN

Il Cremonese innovative 5 sides cabinet “Rhomboidal diamond design” which optimizes the structural solidity of the wooden cabinets with a unique diamond shape that is immediately recognizable thanks to clean lines and an elegant, minimal, and sharp design.

SYSTEM

3.5 way, full para-aperiodic vented box

LOUDSPEAKERS

LOUDSPEAKERS

Tw: H28 XTR-04 DAD Arrow Point, Ø 28 mm
Md: M18 XTR-04 Neodymium Magnet System, Ø 180 mm
W: 2 x W18XTR-12, Ø 180 mm
Sw: 2 x W22XTR-16, Ø 220 mm

CROSSOVER

crossover

80Hz - 250Hz - 2500Hz

FREQUENCY

FREQUENCY RESPONSE

35 Hz – 30.000 Hz, tuning port included

SENSITIVITY

SENSITIVITY

92 db SPL (2.83V/1 m)

NOMINAL IMPEDANCE

NOMINAL IMPEDANCE

4 ohm

POWER

SUGGESTED AMPLIFIER POWER OUTPUT

100W – 800W, without clipping

VOLTAGE

LONG-TERM MAX INPUT VOLTAGE (IEC 268-5)

30 V rms

DIMENSIONS

DIMENSIONS (HxWxD)

1449 x 398 x 621 mm
57 x 15,6 x 24.5 in

WEIGHT

WEIGHT

84 Kg ea – net weight
185 lb ea – net weight
