GIYA G3
SEE FOR YOURSELF
| Specifications | Vivid Audio GIYA G3 Series 2 |
|---|---|
| Configuration | 4-way 5 driver system |
| Cabinet material | Glass reinforced balsa cored sandwich composite, carbon fibre base |
| Cabinet colour | Piano Black, Lexus Pearl White, Oyster Matte |
| Bespoke colour | Any PPG automotive colour available on request |
| Drive units | HF: D26 – 26 mm metal dome unit with Tapered Tube loading Mid: D50 – 50 mm metal dome unit with Tapered Tube loading Lower-mid: C125s, 125 mm alloy cone unit with Tapered Tube loading Bass: C135 – 2 x 135 mm alloy cone unit with short-coil long-gap motor design |
| Bass loading | Exponentially Tapered Tube enhanced bass reflex |
| Sensitivity | 87 dB @ 2.83 VRMS at 1 m on axis |
| Nominal impedacnce (Ω) | 6 nominal, 4 minimum, low reactance |
| Frequency range (Hz) | -6dB points: 33 – 36.000 Hz |
| First D26 Break Up mode: | 44000 Hz |
| Frequency response | 36 – 33.000 Hz +/- 2 dB on reference |
| Harmonic distortion (2nd and 3rd harmonics) |
< 0,5% over frequency range |
| Cross over frequencies (Hz) | 220 – 880 – 3.500 |
| Power handling (music program) watts rms | 800 |
| Loudspeaker dimensions | 1.161mm (H) x 341mm (W) x 578mm (D) |
| Net weight | 42kg |
亲自查看
| 规格 | Vivid Audio GIYA G3 系列 2 |
| 配置 | 4 路 5 驱动器系统 |
| 箱体材料 | 玻璃增强轻木夹芯复合材料，碳纤维底座 |
| 箱体颜色 | 钢琴黑、雷克萨斯珍珠白、牡蛎哑光 |
| 定制颜色 | 任何 PPG 汽车颜色均可应要求提供 |
| 驱动单元 |
HF：D26 – 26 毫米金属圆顶单元，带锥形管负载 |
| 低音负载 | 指数锥形管增强低音反射 |
| 灵敏度 | 87 dB @ 2.83 VRMS，轴上 1 米处 |
| 标称阻抗 (Ω) | 6 标称，4 最小，低电抗 |
| 频率范围 (Hz) | -6dB 点：33 – 36.000 Hz |
| 第一个 D26 分解模式： | 44000 Hz |
| 频率响应 | 36 – 33.000 Hz +/- 2 dB 参考 |
| 谐波失真 （第 2 和第 3 谐波） |
< 0.5% 频率范围 |
| 交叉频率 (Hz) | 220 – 880 – 3.500 |
| 功率处理（音乐节目）瓦特 rms | 800 |
| 扬声器尺寸 | 1.161mm（高）x 341mm（宽）x 578mm（深 |
| 净重 | 42kg |
